Welcome to the KK&L Railroad
The Plywood Railroad

       Steel Mill on the KK&L               Steamer & MEAD in Florida          Industrial town on the KK&L



MASTER MODEL RAILROADER # 641



The gauge of the Railroad's that I model are 7.5 and 1/87 HO scale. The 7.5 is transported to different railroads in and around the area. The HO layout is in my basement. The HO track is code 100 flex track with a gauntlet in a curve.

The railroad runs on car-cards to send the product to the different companies on the layout.

The railroad is a working road that connects two other railroads together. (That makes it a Point to Point Railroad)

The layout is totally freelanced.

The towns and buildings are named after Friends and Family.

The layout covers 1500 sq ft of the basement with 850 ft of dual main line track.

We do have rail ops sessions with training classes.



Click on any picture with the mouse to enlarge the picture







1/87 Scale

North West corner

Lighting the KK&L Railroad

Originally, the layout was illuminated with 75 watt incandescent bulbs. Over time, more energy-efficient bulbs were tried, but the lighting remained uneven and tough on the eyes. Finally, a solution was presented, using 3w LED bulbs housed in used cat food cans. The illumination is now consistent and yet does not strain eyesight when viewed for long periods.

Read More

1/8 Scale

Rebuilding a Steamer from the year 1923

I've always have liked Steam Engines and wanted to own on in 7.5 gauge. A new on was way out of my price range so I needed to build one. I located one that needed allot of work. I decided to take on the challenge to rebuild it. This is how it's going and where it has been.

Read More

When you have a tight space to fill

In Howard yard I have a narrow area to put in some side tracks to run some cars into to make the area more interesting to work. So I designed a building that would take three cars on one side and two cars on the other. This turned into a Z building that when using plastic kits ended up being 2 inches wide. Each of the sides ended up 8 inches long.

Read more

Building Custom Cars

I like to build the riding cars so people have transportation on the track.

Read more

Maid spacers to hold the track in gauge

Running the Gauntlet: Solving a Switching Problem

One of the main curves of the layout had a switch at either end of the single track which no one could keep straight, resulting in head-on collisions and derailments. The fix was to hand-lay and install a Gauntlet at that spot. This is how it went.

Read More



Building Manual Brakes

I needed to go from one height to another in a small area. The way to do this is to run the track back and forth on the wall or fold it over its self. The track is at a 2.3 % grade with the height between the decks at 4 inches in height. It took some planning to get the front tracks to clear the rear tracks going down the grade. Each on of the sections had to be leveled and set to 2.3 % grade.

Read more

0227132009

Building a Helix

I needed to go from one height to another in a small area. The way to do this is to run the track back and forth on the wall or fold it over its self. The track is at a 2.3 % grade with the height between the decks at 4 inches in height. It took some planning to get the front tracks to clear the rear tracks going down the grade. Each on of the sections had to be leveled and set to 2.3 % grade.

Read more

2023 Winter Fest Florida

Glad we were able to make a trip to Florida for the Florida Live Steamers Winter Fest.

Read more

Latest Articles

What do you do after Retirement ?

What do I do now? I was asked if I could build some more riding cars. One that was half gondola and flat car. Well I started to work on a blue print of the car. Went and picked up some steel and started welding. Cut up the metal and put the rivets on the […]

Building of a flat car 7.5

I have built flat cars in the past. Second car I built on the left.     A problem came up that it is hard to ride on a bench seat for any length of time. I have worked on building a car that can carry more than one person.  Here I go…   The […]

2021 End of Summer Heat

OK so it’s the end of summer and the temp is slowly going down. That means it’s time to start building again. I like my fish belly car so what about building more? Started with Two and it grew to Five cars. Three = 6 footers and two =  4 footers. Went and welded stake […]

Digitrax Control Knob Replacement

After twelve years of having many operation sessions on the KK&L Railroad, the knobs on the Digitrax controllers have ether broken off, or the train will not stop when the knob is turned off. The Potentiometers are plastic that are in the controllers. I’m going to replace them. Click on any photo to enlarge it. […]

Fall of 2020

Now that the fall is setting in. I have new projects to work on. I have picked up a new tool and built a cart to hold it. I will be building a new set of riding cars with different options. First I have to build a table. I have already started on two cars […]

Concord Area Model Railroad Club

The Concord Area Model Railroad Club has started up with some meetings. The Club has been asked to go to the North Carolina Transportation Museum in May. So  Keep in touch with the group.

AP Chief Dispatcher

Just a update to the ones that check in. The railroad is back up and running. The track is in the cleaning and repairs to get it back to running status. In 2020 the time’s have been cancelled / postponed as a result of the COVID-19 virus and resulting quarantines. There will be several Operation […]

2020 What a year

Went to Florida to run trains. Was told that the seats were too high. Picked up some lower mounts. Stayed at home for my health. Worked on a tank car to pass the time. Worked on a boxcar to lube the trucks. Started going out riding on the train. Did some ballasting on the main. […]

7.5 Tank car

Looking for something to do I took on a project to build while staying at home in April / May of 2020.   I started by repairing a frame and building straps to hold the tank to the frame. Put the ends on the to check out the fit. Added some detail to the dome. […]

Road Trip to Florida

After the Winter comes Winter Fest in Florida Started from the house. Added Wayne’s to the trailer. Moved every thing over the axles and covered it all. The weather was calling for SNOW in North Carolina. Started at Ridge live steamers with a temp of 76 degrees.  Great bridges to cross over. Orange trees to […]
